Driving GaN Into The Fast Lane

30

Written by:

Ask EPC’s chief executive, Alex Lidow, what the future holds for his GaN power device business, and automotive certification features prominently.

Recently delivering AEC Q101-qualified 80 V discrete transistors for LiDAR, 48V power distribution systems and other applications, the company’s latest enhancement-mode FETs deliver higher switching frequencies and efficiencies than silicon MOSFETs, in a smaller footprint. And this is just the beginning.

“We have more transistors as well as integrated circuits designed for LiDAR [sensors] and are proceeding with automotive certification here,” highlights Lidow. “LiDAR is under intense cost and performance pressure so integrating components and improving performance while lowering the cost is a big deal.”

Read More: https://compoundsemiconductor.net/article/104289/Driving_GaN_into_the_fast_lane





Alex Lidow, Founder and CEO, EPC





Continue reading

eGaN® Technology is Coming to Cars

118

Written by:

Alex Lidow, CEO and Co-founder of Efficient Power Conversion (EPC)

Automotive technology has entered a renaissance with the emergence of autonomous cars and electric propulsion as the driving forces.  IHS Markit estimates that 12 million cars will be autonomous by 2035 and 32 million cars will have electric propulsion according to Bloomberg New Energy Finance, Marklines.  Both trends translate into a large growth in demand for power semiconductors.  This is also happening at a time when silicon is reaching its performance limits in the world of power conversion, thus opening a huge new market for power devices based on gallium nitride grown on a silicon substrate (GaN-on-Si).



Why GaN for cars?

Over the past eight years during which GaN power devices have been in mass production, several large applications where GaN has significant advantages over the aging silicon MOSFET have emerged − LiDAR (Light Detection and Ranging), radar, 48 V – 12 V DC-DC conversion, high-intensity headlamps, and on-board electric vehicle charging.

One of the first applications anywhere for GaN transistors and ICs was LiDAR, prompted by the creative thinking of Dave Hall at Velodyne.  The idea was to trigger laser pulses so fast that the time of the flight of light of the emitted photons could be accurately measured, making it possible to rapidly measure distance within a few centimeters at distances of a few hundred meters.  Using a spinning disk with several solid-state lasers stacked parallel to the axis of rotation, Velodyne was able to create a fast and accurate digital point cloud, such as that shown in figure 1. Much to everyone’s amazement, this sensing technology, combined with cameras and radar sensors, was used by many to create prototype autonomous vehicles.

eGaN for Cars

Figure 1: LiDAR sensors using GaN FETs create a fast and accurate digital point cloud that is used by autonomous cars to identify surrounding structures and obstacles.



eGaN® FETs from EPC were the logical choice to use for firing the laser because the FETs could be triggered to create high-current pulses with extremely short pulse widths (See figure 2).  The short pulse width leads to higher resolution, and the higher pulse current allows the LiDAR system to see further.  These two characteristics, along with their extremely small size, make eGaN FETs ideal for radar and ultrasonic sensors in addition to LiDAR.



eGaN for Cars

Figure 2: An EPC2202 AEC-Q101 qualified FET is used to generate a 1.8 nano-second pulse (yellow trace) at a peak current of 26 A. The optical receiver pulse signal is shown as the blue trace.



LiDAR was just the start of a trend.  Along with the array of sensors used to provide input for navigating and controlling the vehicle, a new market developed for high performance graphic processors to integrate these sensor inputs, digest their meaning, and decide what commands to send to the self-driving actuators.  Fast processing speed being a key attribute, companies such as Mobileye (now part of Intel) and NVIDIA have introduced ultra-fast multicore processors.  These processors can gather, interpret, integrate, and make sense of all the inputs from multiple radar, LiDAR, camera, and ultrasonic sensors quickly enough to safely navigate our roads and highways.

Need for 48 V – 12 V Power Distribution Systems

A cost of these high-performance processors is that they are very power hungry and put an additional burden on traditional automotive 12 V electrical distribution buses.  The solution to providing the high-power levels to these processors needed for automotive LiDAR systems turns out to be the same solution being applied to operate high performance gaming systems, high performance servers, artificial intelligence systems, and even cryptocurrency mining – implementation of a 48 V distribution bus, where current levels and wire sizes can be reduced by a factor of four.  Also, 48 V is the highest practical voltage for these applications because, given overshoot and various fault conditions, the voltage on the bus will stay below 60 V, avoiding the need for additional (and costly) safety measures.

The advantages of 48 V become even more evident when all the new power hungry electronically-driven functions and features appearing on the latest cars are considered.  For example:

  • Electric start-stop
  • Electric steering
  • Electric suspension
  • Electric turbo-supercharging
  • Variable speed air conditioning

These new functions and features are opening a large new market for 48 V – 12 V DC-DC converters.  Power can be generated at 48 V and converted to 12 V to run legacy systems and battery packs.

Superior Performance of GaN FETs and ICs

GaN FETs and ICs are the most efficient way to get from 48 V to 12 V as shown in figure 3.  GaN devices are many times smaller than a silicon power MOSFET, and many times faster [1] which leads to higher efficiency as well as smaller, lower cost peripheral components.  eGaN FETs from EPC are also on par with silicon when it comes to volume pricing [2].  Now the technology is taking the next step to wide-spread adoption by the automotive world by passing AEC-Q101 qualification testing.

Figure 3: The EPC9130 is a 700 W 48 V – 12 V DC-DC converter based on EPC2045 eGaN FETs. It has higher power density and higher efficiency than the best silicon-based converters. The eGaN FET-based converter also has the lowest cost bill of materials.

eGaN technology has been in mass production for over eight years, accumulating billions of hours of successful field experience in automotive applications.

AEC-Q101 Qualified eGaN FETs

EPC is offering its first two products that have completed AEC-Q101 qualification testing.  The products, EPC2202 (figure 4) and EPC2203 (figure 5), are discrete transistors in wafer level chip-scale packaging (WLCS) with 80 VDS ratings. These first AEC-Q101 qualified products will soon be followed with several more discrete transistors and integrated circuits designed for the harsh automotive environment.

Figure 4: The 80 V EPC2202 device passed AEC-Q101 testing. It measures 2.1 x 1.6 mm and has a pulsed current rating of 75 A.



















Figure 5: The 80 V EPC2203 device passed AEC-Q101 testing. It measures 0.9 x 0.9 mm and has a pulsed current rating of 18 A.

















The EPC2202 is an 80 V, 16 mΩ enhancement mode FET with a pulsed current rating of 75 A in a 2.1mm x 1.6mm chip-scale package. The EPC2203 is an 80 V, 73 mΩ part with a pulsed current rating of 18 A in a 0.9mm x 0.9mm chip-scale package. These eGaN FETs are many times smaller and achieve switching speeds 10 – 100 times faster than their silicon MOSFET counterparts.  Both products are designed for a wide range of emerging automotive applications including:

  • LiDAR
  • 48 V – 12 V DC-DC Converters
  • High Intensity Headlights
  • Ultra-high Fidelity Infotainment Systems

To complete AEC-Q101 testing, these eGaN FETs had to undergo rigorous environmental and bias-stress testing including humidity testing with bias (H3TRB), high temperature reverse bias (HTRB), high temperature gate bias (HTGB), temperature cycling (TC), as well as several other tests.  Of note is the fact that these wafer level chip-scale (WLCS) devices passed all the same testing standards created for conventional packaged parts, demonstrating that the superior performance of chip-scale packaging does not mean a compromise to ruggedness or reliability. These parts are produced in facilities certified to the Automotive Quality Management System Standard IATF 16949.

Conclusion: eGaN® Technology is Coming to Cars

Automotive electronics can now take full advantage of the improved efficiency, speed, smaller size, and lower cost of eGaN devices with the completion of the AEC-Q101 qualification testing of the EPC2202 and EPC2203.  Throughout 2018 there will be several additional 80 V parts undergoing certification, expanding the range of performance to higher currents.

References:

[1] A. Lidow, J. Strydom, M. de Rooij, D. Reusch, GaN Transistors for Efficient Power Conversion, Second Edition, Wiley, 2014.

[2] R. Cortland, “Gallium Nitride Power Transistors Priced Cheaper Than Silicon,” IEEE Spectrum, 8 May 2015







Continue reading

EPC’s Wireless Power Fix: Get a Load of This Antenna

479

Written by:

Continue reading

Alex Lidow, CEO of Efficient Power Conversion, was a guest on ‘TWiT TV’ Netcast Network

530

Written by:

Technology

Alex shares with Leo a few of the applications where GaN is changing the way we live. https://twit.tv/shows/triangulation

Continue reading

IEEE Electron Devices Society Webinar – “GaN Devices and Applications” Presented by: Dr. Alexander Lidow

453

Written by:

GaN devices and Applications Abstract

GaN Transistors – Giving New Life to Moore’s Law

Enhancement-mode gallium nitride transistors have been commercially available for over eight years and have infiltrated many applications previously monopolized by the aging silicon power MOSFET.  In this presentation, we will discuss the state-of-the-art and the expected progress of GaN technology over the next few years, showing that Moore’s Law is alive and well in the world of power semiconductor technology.  We will also enumerate the advantages of GaN over silicon in terms of performance, cost, and reliability. | http://epc-co.com/epc/EventsandNews/Events.aspx

Moore's Law





Continue reading

Nobody Likes Power Cords, Wireless Power is Happening

593

Written by:

I have yet to meet someone who likes power cords.

Take for example Keith. In figure 1 is a photo of all the power-related accessories Keith lugs around in his backpack to make certain he will be able to run his phone, tablet, and computer wherever he goes. What Keith and others may not realize is that the technology is available that can eliminate every one of these cords – today! So, why is it taking so long for wireless power solutions to become a household technology?

Read more on GaN Talk

Cords

Keith’s Cords

Continue reading
